Salesforce REST API Integration: Step-by-Step Guide to Connecting External Systems with Apex

By Firus Hanov · February 28, 2026 · 10 min read

Build Salesforce REST integrations: outbound callouts with Named Credentials, inbound @RestResource endpoints, async patterns, error handling, and retry logic.

Modern Salesforce implementations almost never stand alone. Your org needs to talk to ERP systems, payment processors, marketing platforms, shipping providers — the list goes on. And most communicate via REST APIs.

In this guide, I'll show you how to build both sides: calling external APIs from Salesforce (outbound), and exposing Salesforce data to external systems (inbound). 🔥

Fundamentals: Named Credentials

Before writing callout code, set up a Named Credential. Named Credentials store endpoint URLs and authentication settings so your code never hard-codes credentials.

HttpRequest request = new HttpRequest();
request.setEndpoint('callout:External_CRM/contacts');
request.setMethod('GET');

Why Named Credentials matter:

No hard-coded credentials in code
URL changes are configuration, not deployments
Authentication handled automatically (OAuth token refresh, etc.)
Works across environments

Part 1: Outbound Callouts

The Basic Callout Pattern

public class ExternalAPIService {
    private static final String NAMED_CREDENTIAL = 'External_CRM';

    public static HttpResponse makeGetRequest(String path) {
        Http http = new Http();
        HttpRequest request = new HttpRequest();
        request.setEndpoint('callout:' + NAMED_CREDENTIAL + path);
        request.setMethod('GET');
        request.setHeader('Content-Type', 'application/json');
        request.setTimeout(30000);
        return http.send(request);
    }

    public static HttpResponse makePostRequest(String path, String jsonBody) {
        Http http = new Http();
        HttpRequest request = new HttpRequest();
        request.setEndpoint('callout:' + NAMED_CREDENTIAL + path);
        request.setMethod('POST');
        request.setHeader('Content-Type', 'application/json');
        request.setBody(jsonBody);
        request.setTimeout(30000);
        return http.send(request);
    }
}

Parsing the Response

public class ContactSyncService {
    public static void syncContactToExternalCRM(Contact contact) {
        Map<String, Object> payload = new Map<String, Object>{
            'externalId' => contact.Id,
            'firstName' => contact.FirstName,
            'lastName' => contact.LastName,
            'email' => contact.Email
        };
        String jsonBody = JSON.serialize(payload);
        HttpResponse response = ExternalAPIService.makePostRequest('/contacts', jsonBody);

        if (response.getStatusCode() == 200 || response.getStatusCode() == 201) {
            Map<String, Object> responseBody = (Map<String, Object>)
                JSON.deserializeUntyped(response.getBody());
            String externalId = (String) responseBody.get('id');
            contact.External_CRM_Id__c = externalId;
            update contact;
        } else {
            throw new CalloutException('Sync failed: ' + response.getStatusCode());
        }
    }
}

Strongly-Typed JSON Parsing

public class ExternalContact {
    public String id;
    public String firstName;
    public String lastName;
    public String email;
    public ExternalAddress address;

    public class ExternalAddress {
        public String street;
        public String city;
        public String state;
    }
}

// Parsing:
ExternalContact ec = (ExternalContact) JSON.deserialize(response.getBody(), ExternalContact.class);

Async Callouts (Avoiding DML + Callout Conflicts)

// @Future approach
@Future(callout=true)
public static void syncContact(Id contactId) {
    Contact c = [SELECT Id, FirstName, LastName, Email FROM Contact WHERE Id = :contactId];
    ContactSyncService.syncContactToExternalCRM(c);
}

// Queueable approach — more flexible
public class ContactSyncQueueable implements Queueable, Database.AllowsCallouts {
    private Id contactId;
    public ContactSyncQueueable(Id contactId) { this.contactId = contactId; }
    public void execute(QueueableContext context) {
        Contact c = [SELECT Id, FirstName, LastName, Email FROM Contact WHERE Id = :contactId];
        ContactSyncService.syncContactToExternalCRM(c);
    }
}

Error Handling and Retry Logic

public class ResilientCalloutService {
    private static final Integer MAX_RETRIES = 3;

    public static HttpResponse callWithRetry(String path, String method, String body) {
        HttpResponse response;
        Integer attempts = 0;
        Exception lastException;

        while (attempts < MAX_RETRIES) {
            try {
                Http http = new Http();
                HttpRequest request = new HttpRequest();
                request.setEndpoint('callout:External_CRM' + path);
                request.setMethod(method);
                request.setHeader('Content-Type', 'application/json');
                if (String.isNotBlank(body)) request.setBody(body);
                request.setTimeout(30000);
                response = http.send(request);

                if (response.getStatusCode() >= 500) {
                    attempts++;
                    continue;
                }
                return response;
            } catch (Exception e) {
                attempts++;
                lastException = e;
            }
        }
        throw lastException;
    }
}

Part 2: Inbound REST — Exposing Salesforce Data

@RestResource(urlMapping='/contacts/*')
global with sharing class ContactRESTService {

    @HttpGet
    global static Contact getContactById() {
        RestRequest req = RestContext.request;
        String contactId = req.requestURI.substringAfterLast('/');
        if (String.isBlank(contactId)) {
            RestContext.response.statusCode = 400;
            return null;
        }
        try {
            return [SELECT Id, FirstName, LastName, Email, Phone FROM Contact WHERE Id = :contactId WITH SECURITY_ENFORCED LIMIT 1];
        } catch (QueryException e) {
            RestContext.response.statusCode = 404;
            return null;
        }
    }

    @HttpPost
    global static RestResponse createContact() {
        RestRequest req = RestContext.request;
        RestResponse res = RestContext.response;
        RestResponse result = new RestResponse();
        try {
            Map<String, Object> params = (Map<String, Object>) JSON.deserializeUntyped(req.requestBody.toString());
            Contact c = new Contact(
                FirstName = (String) params.get('firstName'),
                LastName = (String) params.get('lastName'),
                Email = (String) params.get('email')
            );
            if (String.isBlank(c.LastName)) {
                res.statusCode = 400;
                result.message = 'lastName is required';
                return result;
            }
            insert c;
            res.statusCode = 201;
            result.id = c.Id;
            result.message = 'Contact created successfully';
            return result;
        } catch (Exception e) {
            res.statusCode = 500;
            result.message = e.getMessage();
            return result;
        }
    }

    global class RestResponse {
        global String id;
        global String message;
    }
}

Authentication for Inbound Calls

External systems must authenticate via OAuth 2.0 Bearer Token or Connected App. The OAuth 2.0 Client Credentials flow is cleanest for server-to-server integration.

Testing Callouts

@IsTest
private class ContactSyncServiceTest {
    @IsTest
    static void testSyncContact_success() {
        Test.setMock(HttpCalloutMock.class, new MockHttpCallout(201, '{"id": "EXT-12345"}'));
        Contact c = new Contact(FirstName = 'Test', LastName = 'Contact', Email = '[email protected]');
        insert c;
        Test.startTest();
        ContactSyncAsync.syncContact(c.Id);
        Test.stopTest();
    }

    public class MockHttpCallout implements HttpCalloutMock {
        private Integer statusCode;
        private String body;
        public MockHttpCallout(Integer statusCode, String body) {
            this.statusCode = statusCode;
            this.body = body;
        }
        public HTTPResponse respond(HTTPRequest req) {
            HttpResponse response = new HttpResponse();
            response.setStatusCode(this.statusCode);
            response.setBody(this.body);
            return response;
        }
    }
}

Production-Ready Checklist

Outbound:

✅ Named Credentials for endpoint/auth
✅ @Future(callout=true) or Queueable
✅ Timeout set (max 120s)
✅ Error handling with retry logic
✅ HttpCalloutMock in tests

Inbound:

✅ @RestResource with clear URL mapping
✅ with sharing and WITH SECURITY_ENFORCED
✅ Input validation with meaningful errors
✅ Proper HTTP status codes
✅ Connected App for authentication

Need help building an integration? Start practicing on ApexSensei →

What system are you integrating with Salesforce? Tell me in the comments. 💬
